Centa CENTAX-L - Wearing and Spare Parts

Assembly and operating instructions
CENTAX-L
016L-00050…00090-FS10
M016-00003-EN
Rev. 3
CENTA Antriebe Kirschey GmbH 44 / 46
10 Wearing and spare parts
WARNING
Injury and material damage can occur as a result of:
 Mounting and/or utilization of non-original CENTA parts
Never use parts from other manufacturers.
A stock of the most important wearing and spare parts is the most important
condition to ensure that the coupling is functional and ready for operation at all
times.
We only provide a warranty for CENTA original parts.
Wearing parts of this coupling:
 The link kits. These contain all screws, washers and bearing units. In the
event that links or rubber bushes of the link are faulty, they must be
replaced as a complete set.
 The rubber element(s). When exchanging the rubber element(s), all screw
connections must be renewed. These must be ordered separately.
IMPORTANT
 Links are packaged in sets.
 All links of a link set are the same weight.
 Only mount or replace links in complete sets.
When ordering a spare, specify:
 Order no.
 Coupling order no.
 Drawing no.
