CAUTION
Material damage can occur as a result of:
 Incorrect heating of the hubs/flange hubs
Heat the hubs/flange hubs steadily in an oil bath, a fan oven, on an
electric hot plate, either inductive or with a flame (ring burner).
CAUTION
Injuries can occur as a result of:
 Hot coupling components
Use suitable protective gloves.
 Heat the hub (3) to a temperature of 170° - 200°C.
 Push the hub (3) onto the shaft (A).
IMPORTANT
Face of shaft must not protrude to face of hub. Otherwise radial replacement of other
coupling parts is not guaranteed.
CAUTION
Material damage can occur as a result of:
 Hot hubs/flange hubs
Before further mounting of hubs/flange hubs, allow them to cool to
ambient temperature.
