chapter 5000
page 80
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
STEERING POTENTIOMETER ADJUSTMENT (MASTER connection
number 3)
The setting of the steering potentiometer is made in the MASTER (connection number 3) of the traction logic
unit, that is automatically selected when the console is fisically connected to the MASTER unit.
Press ROLL and PARAM together
Press ROLL
Press ROLL
Press ENTER
Scroll the parameters using ROLL
1. Select MAX STEER RIGHT (pressing ENTER
to delete the old parameter) with the wheels turned
completely right and store the parameter pressing
OUT and then ENTER to confirm. (This value
corresponds to the min. voltage)
2. Select MAX STEER LEFT (pressing ENTER to
delete the old parameter) with the wheels turned
completely left and store the parameter pressing
OUT and then ENTER to confirm. (This value
corresponds to the max. voltage)
3. Select SET STEER 0-POS (pressing ENTER to
delete the old parameter) with straight wheels and
store the parameter pressing OUT and then ENTER
to confirm the new value.
* CONFIG. MENU *
SET MODEL
* CONFIG. MENU *
SET OPTIONS
* CONFIG. MENU *
ADJUSTMENTS
DA2M2B C CE 1.13
48V 280A 00000
SET POT BRK MIN ....V
SET POT BRK MAX ....V
SET BATTERY TYPE 48/72/80/96
ADJUST BATTERY ....V
MAX STEER RIGHT ....V
MAX STEER LEFT ....V
SET STEER 0-POS 2.5V
SET STEER RIGHT ....°
SET STEER LEFT ....°
THROTTLE 0 ZONE ....%
THROTTLE X ZONE ....%
THROTTLE Y ZONE ....%
ADJUSTMENT #02 1-9
ADJUSTMENT #01 1-9
MAIN CONT VOLT ....V
AUX OUTPUT VOLT ....V
