Table 5-3 Energy Measurements
Note:
The Energy registers have a maximum value of 999,999,999 in units of 0.1 kXh and will roll over
to zero automatically when it is reached.
5.3 Peak Demands
The value of the Peak Demand register is 1000 times the actual value.
Table 5-4 kW Peak Demand
Peak Demand High-order Word
Peak Demand Low-order Word
UNIX Time High-order Word
Table5-5 DMD-LOG Data Structure
5.4 Harmonic Measurements
The value of the THD returned is 10000 times the actual value. For example, if the register contains a
value of 1031, the actual harmonic value is 0.1031 or 10.31%. The value of the K Factor data
returned is 10 times the actual value.
Table 5-6 Harmonics Measurements
