CET PMC-53 Series User Manual

Ceiec Electric Technology
42
5.5 Setup Parameters
Register
Property
Description
Format
Range/Unit
PMC-53 Model
V
I
M
41000
RW
I residual
ALARM
Setpoint
1
UINT16
30 to 1000 (mA)
(Default = 500)
■
41001
RW
I residual
ALARM Delay
1
UINT16
0 to 600 (x0.1s)
(Default = 20)
■
41002
RW
I residual TRIP
Delay
1
UINT16
0 to 600 (x0.1s)
(Default = 20)
■
41003
RW
Temperature
ALARM Delay
2
UINT16
0 to 400 (x0.1s)
(Default = 20)
■
41004
RW
I residual TRIP
Setpoint
1
UINT16
30 to 1000 (mA)
(Default = 500)
■
41005
RW
Temperature
ALARM
Setpoint
2
UINT16
55 to 140 (°C )
(Default = 80)
■
41006
RW
Alarm Enable
1,2
Bitmap
3
■
41007-
41009
Reserved
41010
RW
PT Ratio
4
UINT16
1* to 2200
■
■
41011
RW
CT Ratio
4
UINT16
1* to 6000(5A input)
1* to 30000(1A input)
■
■
41012
RW
Wiring Mode
UINT16
0=WYE*
1=DELTA
2=DEMO
■
■
41013
RW
Unit ID
UINT16
1 to 247
(Default = 100)
■
■
■
41014
RW
Baud rate
UINT16
0=1200
1=2400
2=4800
3=9600*
4=19200
■
■
■
41015
RO
Comm. Config.
UINT16
0=8N2
1=8O1
2=8E1*
3=8N1
4=8O2
5=8E2
■
■
■
41016
- 41018
Reserved
41019
WO
Clear Energy
UINT16
Writing “0xFF00” to the
register clears the kWh,
■
