CET PMC-53 Series User Manual

Ceiec Electric Technology
45
Register
Property
Description
Format
Mode
V
I
M
42000-42006
RO
Event 1
See
Table 5-11
SOE LOG
Data
Structure
■
■
■
42007-42013
RO
Event 2
■
■
■
42014-42020
RO
Event 3
■
■
■
42021-42027
RO
Event 4
■
■
■
42028-42034
RO
Event 5
■
■
■
42035-42041
RO
Event 6
■
■
■
42042-42048
RO
Event 7
■
■
■
42049-42055
RO
Event 8
■
■
■
42056-42062
RO
Event 9
■
■
■
42063-42069
RO
Event 10
■
■
■
42070-42076
RO
Event 11
■
■
■
42077-42083
RO
Event 12
■
■
■
42084-42090
RO
Event 13
■
■
■
42091-42097
RO
Event 14
■
■
■
42098-42104
RO
Event 15
■
■
■
42105-42111
RO
Event 16
■
■
■
……
42217-42223
RO
Event 32
■
■
■
Table 5-10 SOE Log
Notes:
1) SOE LOG Data Structure
Offset
Property
Description
+0
RO
Reserved
+1
RO
Event Classification (See Table 5-12)
+2
RO
Event Value High-order Word
+3
RO
Event Value Low-order Word
+4
RO
Event Time Millisecond (0 to 999)
+5
RO
Event Time High-order Word (UNIX time in Second)
+6
RO
Event Time Low-order Word (UNIX time in Second)
Table 5-11 SOE LOG Data Structure
2) SOE Event Classification
Value
1
2
3
4
Meaning
DI1 close
DI1 open
DI2 close
DI2 open
Value
11
12
13
14
Meaning
DO1 close
DO1 open
DO2 close
DO2 open
Value
22
31
32
33-40
Meaning
Power Outage
Setup Changes via
Front Panel
Setup Changes via
Communications
Reserved
Value
41
42
43
44
Meaning
DI1 triggered DO1
DI1 triggered DO2
DI2 triggered DO1
DI2 triggered DO2
