CET PMC-53 Series User Manual

Ceiec Electric Technology
51
Accuracy
Frequency
Line length
Dielectric Strength
I residual Sensor Models
1%
50 / 60Hz
4000mm
2.5kV @ 1 minute
PMC-MIR-35, PMC-MIR-50, PMC-MIR-75, PMC-MIR-120
RTD Temperature Sensor
Material
Range
Accuracy
Cable Length
Protective Tube Length
RTD Models
Platinum Resistor Pt100
-50°C to 200°C
±(0.30+0.005|t|)
3000mm
30mm
PMC-DN-30, PMC-DN-50, PMC-DN-55, PMC-DN-60
Environmental Conditions
Operating Temp.
Storage Temp.
Humidity
Atmospheric Pressure
-25°C to 70°C
-40°C to 85°C
5% to 95% non-condensing
70 kPa to 106 kPa
Mechanical Characteristics
Panel Cutout
Unit Dimensions
IP Rating
Shipping Weight
Shipping Dimensions
Measurement Category
92x92 mm (3.62”x3.62”)
96x96x75 mm (3.8˝x3.8˝×3.0˝)
52
0.55 kg
170x160x150 mm (6.7˝x6.3˝×5.9˝)
III
Accuracy
Parameters
Accuracy
Resolution
Voltage
±0.2% reading
0.01V
Current
±0.2% reading + 0.05% F.S.
0.001A
Neutral Current
1% F.S.
0.001A
kW, kVA
IEC 62053-22 Class 0.5S
0.001k
kWh, kVAh
IEC 62053-22 Class 0.5S
0.1kXh
kvar / kvarh
IEC 62053-21 Class 2
0.001k / 0.1kvarh
P.F.
IEC 62053-22 Class 0.5S
0.001
Frequency
±0.02 Hz
0.01Hz
THD
IEC 61000-4-7 Class B
0.1%
K-Factor
IEC 61000-4-7 Class B
0.1
Phase angles
±1°
0.01°
I residual
±1% F.S.
0.1mA
Temperature
±1°C
0.1°C

CET PMC-53 Series Specifications

General

Brand	CET
Model	PMC-53 Series
Category	Measuring Instruments
Language	English
