MAINTENANCE
151
Head light replacement
1. Access the headlight lamp:
Remove the cover ② ③ from the headlight
assembly ① by turning it counter-clockwise.
Remove the cover to expose the headlight lamp.
2. Remove the headlight lamp lock spring.
3. Disconnect the failed bulb, pull it out, and replace it
with a new bulb.
4. Reinstall the bulb and lock spring into the headlight
housing.
5. Reinstall the cover and turn it clockwise.
6. Test the head light and ensure it is working
properly.
NOTE:
The position lamp and turning lamp (if equipped) assemblies are an LED structure, which cannot be
repaired if damaged or failed. Have your dealer replace the entire assembly if an LED is damaged
or has failed.
Hot surface. Touch the bulb only after it has cooled down.
Do not touch the bulb surface. Use gloves or other
protection to keep oils and dirt off the bulb.
