(individually
selectable for each
input)
Normal
Processor
scrolling though inputs (with remote control or
encoder).
For “Processor” inputs, the L1's volume control is
not applied (no attenuation!)
Only available inputs (depends on hardware
configuration) can be enabled/disabled in the menu
INPUT COUPLING
(individually
selectable for each
input)
Direct coupling
DC-blocking
None Direct coupling means absolutely no capacitor is
present on the signal path. DC-cancellation is taken
care of by an advanced DSP-controlled analog
stage.
DC-Blocking means a coupling capacitor is
connected to remove excessive DC from the
upstream device.
INPUT IMPEDANCE
(individually
selectable for each
input)
HighZ (high impedance)
600/300 Ohm
None High impedance means the input won't draw any
current from the upstream device's output.
600 Ohm (300 Ohm for single-ended inputs) means
a termination resistor is activated, increaing the
noise immunity of the interconnect while drawing a
bit of current from the upstream device's output
INPUT GAIN
(individually
selectable for each
input)
-24 dB to +24 dB by 0.5
dB steps
None Allows all L1's input level to match, even if
upstream component have different output levels.
INPUT CALIBRATION
(individually
selectable for each
input)
Start calibration None Analyzes upstream device's DC level to best adapt
its DC-cancellation scheme
MONO MODE Stereo
Mono
Dual-monaural
configuration
Allows to sum both input channels and output it to
all outputs
BALANCE Left +6 dB to Right +6
dB by 0.5 dB steps
Dual-monaural L+R
configuration
Adjust the L/R balance
CHANNEL GAIN -6 dB to +6 dB by 0.5
dB steps
True-monaural, Ls+Rs or
C+Sub configuration
Replaces balance setting when multiple L1s are used
MAX START VOL -50 dB to -20 dB by 10
dB steps
None The startup volume is the lowest of the following:
- Last listening volume before standby
- MAX START VOL parameter value
MAX VOLUME -30 dB to 0 dB by 10 dB
steps, or no limitation
(up to +18 dB)
None Limits the output volume of the L1
Details of the AUDIO SETTING menu
34 L1 User Manual Rev 1.0
