7 Specifications
7.1 Specifications
General
User control Dual concentric rotary knob with push function (control knob)
Display 480 x 272 24bits RGB AMOLED
Power supply Selectable 100V, 115V or 230V AC, 47Hz to 63Hz
Power consumption (Standby) < 1W
Power consumption (Normal operation) 40W average
Operating conditions Temperature: +5C to +35C, humidity: 5% to 85% (no condensation)
Dimensions (L x D x H) 440mm x 440mm x 120mm (main body)
Weight 20kg
Software update / Control USB port for firmware update / Ethernet based system control
Analog inputs
Balanced inputs
4x XLR connectors per board, 100k or 600 load (user selectable)
Single-ended inputs
2x RCA connectors per board, 50k or 300 load (user selectable)
2x BNC connectors per board, 50k or 300 load (user selectable)
Maximum input level 16Vrms (balanced), 8Vrms (unbalanced)
Analog outputs
Balanced outputs 2x XLR connectors per board
Single-ended outputs 1x RCA connector per board, 1x BNC connector per board
Output level Up to 16Vrms (balanced), Up to 8Vrms (unbalanced)
Frequency response (-3dB point) DC-1MHz
Signal to Noise Ratio (SNR) 130dB, unity gain and at maximum input level
Total Harmonic Distortion + Noise (THD+N) <0.001%, 1kHz, unity gain
Remote control
Remote control type Infrared. Uses RC5 codes. Range: 10m (line of sight)
Remote control batteries 2x AAA type
Specifications
Design and Specifications are subject to change without notice. Weight and dimensions are approximate
Illustrations are informative only and may differ from the actual production model
Casing designed by Mana Ishoni
46 L1 User Manual Rev 1.0
