2.3.CHM-T48VB
model
CHMT48VB
X,Y Z axis stroke
510mm(X)*460mm(Y)*15mm(Z)
PCB area
345*355mm
Component support
0402~5050, SOP, QFN and etc
Material support
8mm, 12mm, 16mm, 24mm
mount speed
do not use the visual: 6000 cph (max)
use visual: 4000 cph
Note: cph is chip per hour
SMT precision
±0.025mm
Nozzle
2
Material system
58pcs material stack
14pcs IC stack
Support custom IC tray
Visual system
Up camara automatic adjust(max 22mm*22mm)
Down camara PCB automatic MARK adjust
Controlling system
XY axis with motor for driving
Z axis with reset detection
All motors with S flexibility lower or faster speed
Pull needle auto reset
Vacuum detection
With 2 big no noise vacuum air pump, no need external air
pump
Air pressure: -92KPa
Leak detection
Vacuum detection, visual detection
Controlling PC
With good quality industrial PC
7 inch LCD touch screen
Embedded Linux system
Compatible software
Altium Designer
Power
AC 220V 50HZ/AC 110V 60HZ
Dimension
1320mm(L)*705mm(W)*335mm(H)
Power
250W
Net weight
89Kg
