DF II Series User Manual 35
SELECTING LOW LIMIT SETPOINT
The LOW Limit Setpoint is the load value repre-
senting the lowest TENSION load value that you
want your gauge to measure prior to it giving a
Load Limit indication. The LOW Load Limit is a
negative number or zero.
0 lbf
-50 lbf
Low Limit
(Tension)
Use the F1 key to select the LOW Load Limit. The
cursor arrow will automatically be placed next to
the LOW Load Limit tag indicating that you are
about to adjust this value.
Use the UP and DOWN navigation key to increase
or decrease the Low Load Limit VALUE. The value
will increase by the increment selected upon each
key press.
Select enter after both the High and Low Limits
have been adjusted.
VIEWING LOAD LIMIT RESULT
The DF II Series gauge will display “L-T” if a Low
Load (Tension) Limit has been reached, or “L-C”
if a High Load (Compression) Limit has been
reached. The Limit tag displays until the measured
resultfallsaboveorbelowtheuser-speciedlimit.
Load Limit indications are displayed in any mode.
