Key
Item Description
7 LAN1 -
LAN16, DMZ,
WAN LEDs
Speed Indicator:
• Orange when the port speed is 1000 Mbps.
• Green when the port speed is 100 Mbps.
• Not lit when the port speed is 10 Mbps.
Activity Indicator:
• Not lit when there is no link.
• Green when there is a link but no traffic encountered.
•
Blinking green when encountering traffic.
8 SD LED Green when SD Card is inserted.
9 Console port RJ45 or Mini USB Serial connection
configured to 115200 bps by default.
Note - When both the RJ45 and Mini USB
cables are connected, the Mini USB takes
precedence.
