Key Item Description
6 Internet LED
• Blinking green when trying to connect to the
Internet.
• Green when connected to the Internet.
•
Blinking red when the Internet connection is
configured but fails to connect.
7 LAN1-LAN16,
WAN
DMZ:
F – Fiber
C - Copper
Speed Indicator:
• Orange when the port speed is 1000 Mbps.
• Green when the port speed is 100 Mbps.
• Not lit when the port speed is 10 Mbps.
Activity Indicator:
• Not lit when there is no link.
• Green when there is a link but no traffic
encountered.
• Blinking green when encountering traffic.
8 SD LED Green when SD Card is connected.
9 PoE-MAX
• Not lit when the total power consumption is below
62W.
• Red when the total power consumption is over
62W.
10 Console Port RJ45 or Mini USB Serial connection
configured to 115200 bps by default.
Note - When both the RJ45 and Mini
USB cables are connected, the Mini
USB takes precedence.
