SR113 Family

1-5 Chassis Dimensions

Figure 14 Chassis dimensions

1-6 Interior view

Figure 15 Chassis components

A. 4-Bay SAS/SATA hot-swap module

B. Rear 80mm system fan kit, internal

C. External 80mm GPU hot-swap fan

module

D. GPU cards fix bracket

E. Fan bar

F. Fan wall

G. Middle 80mm fan module, hot swap

H. Power distribution board

I. Motherboard

J. Card retainer

K. Redundant CPRS module
