Chenbro SR113 Series User Manual

SR113 Family
1. Product Overview
The SR113 chassis has been modified to support both tool-less 3.5” HDD tray and PCI-e 3.0 slot, and transformed into feature-
advanced SR107 Plus. Beneath the chassis, an information sticker reads revision and manufacturing code, necessary for technical
support.
Table 1 Chenbro SR113 specifications
M/B Form Factor
 Proprietary (15.12” x 13.2”): Super Micro X11DGP-QT/X11DPX-T
 Proprietary (14.23” x 13.24”): Tyan S7105
 SSI EEB (12”x 13”): Support 8-slot PCIe SKU only
Dimension (D x W x H)
680.0 x 175.0 x 438.0 (mm) ; 26.77" x 6.89" x 17.24”
Drive Bay
 External: 2 x 5.25” and 1 x 3.5”
 Hot-Swap: 2 x 4-Bay 3.5” SAS/SATA Hot Swap module
Storage Backplane
12Gb/s miniSAS-HD
PSU Form Factor
 Redundant CRPS 1+1, 2000W (80+ Platinum)
 Single PS2 (*support 8 PCIe slot SKU only)
Indicators
1 x Power Status, 1 x HDD Activity, 2x LAN Activity, 1 x System Alarm, 1 x UID
Front Control
1 x Power On/Off, 1 x System Reset, 2 x USB3.0, 1 x Audio combo
Cooling Fans
 Middle (Default): 4 x 80mm, PWM, 11000RPM, Hot-Swap
 Rear CPU fan module for internal: 2 x 80mm, PWM ,8200RPM, Fixed (Option)
 Rear GPU hot-swap fan for external: 2 x 80mm, PWM, 11000RPM, Hot-Swap (Option)
System Security
Intrusion Switch; Key Lock on front bezel
Expansion Slot
 11 x Full Height and Full Length (Up to double width 5 x GPU support)
 8 x Full Height and Full Length (Up to double width 4 x GPU support)
(*Card retainer needs option)
Supported rack mount kit
(Options)
 Rackmount handles
 Slide rail kit can support CMA: Works for 438 mm width rack chassis, P2P: 26" to 36.7",
Traveling Distance 28.5", Tool-less
 Cable Management Arm
Net Weight
25KG/PCS
Gross Weight
26KG/CTN
Cubic Feet
5.77
Pallet size (L x W x H)
1200 x 1000 x 126 (mm)
Cartons per pallet
6PCS
Container Loading
20' FCL: 96pcs / 40' FCL: 192pcs / 40' H: 224pcs (Single Packing)
