SR113 Family
2. System Components Installation and Removal
SR113 supports up to 8 x 3.5” hot-swap SAS/SATA HDD or 8 x 3.5” Internal SAS/SATA HDD. Support for different storage and
peripheral options will vary depending on the system model and/or available accessory options installed.
2-1 Side Cover Installation
Figure 16 Side cover installation
1. Check if the thumb screws on the side cover are loosened.
2. Check if the lock on the latch is unlocked.
3. Press the blue button on the latch, grad the latch as a handle and move it toward the rear side of chassis.
