SR113 Family
1-1 System Outlook Overview
Figure 1 SR113 Tower
A. Front Bezel Lock
B. Indicator
C. Front Bezel (Security)
D. Foot Stand
Figure 2 SR113 4U Rackmount
A. Ear Handle
A
B
C
D
A
