CHINT NVF5 Series User Manual

NVF5 Series User Manual Appendix B Parameter list
Code
Name
Setting Range
Default
Change
F4.04
Multi-point VF
Voltage Point 3
（ 0.0 ～ 100.0）%
0.0%
◎
F4.05
Multi-point VF
Frequency Point 2
F4.07 ～ F4.03
0.00Hz
◎
F4.06
Multi-point VF
Voltage Point 2
（ 0.0 ～ 100.0）%
0.0%
◎
F4.07
Multi-point VF
Frequency Point 1
0.00 ～ F4.05
0.00Hz
◎
F4.08
Multi-point VF
Voltage Point 1
（ 0.0 ～ 100.0）%
0.0%
◎
F4.09
VF Slip Compensation
Gain
（0.0 ～ 200.0）%
100.0%
○
F4.10
VF Excessive Flux
Gain
0 ～ 200
64
○
F4.11
VF
Oscillation
Suppression Gain
0 ～ 100
Depend on
machine
type
○
F4.12
VF Separation Output
Voltage Channel
0：Keypad Setting
1：AI1
2：AI2
3：Reserve
Note：
100% Corresponding Motor
Rated Voltage
0
○
F4.13
VF Separation Voltage
Digital Given
（ 0.0 ～ 100.0 ） %
0.0%
○
F4.14
VF Separation Voltage
Rising Time
（ 0.0 ～ 10.0 ） s
0.5s
○
F4.15
VF Separation Voltage
Dropping Time
（ 0.0 ～ 10.0 ） s
0.5s
○
F4.16
VF Separation Max.
Output Voltage
F4.17 ～ 100.0%
100.0%
○
F4.17
VF Separation Min.
Output Voltage
0.0% ～ F4.16
0%
○
F5 Digital Input Terminal Group
F5.00
HDI
Input Type
Selection
0：HDI-High Speed Pulse Input
（Set F5.15～F5.18 ）
1：Common DI（Same as DI1～
DI4）
0
◎
F5.01 DI1 Setting
0 ～ 63
0：No Applicable
1：Run Forward-FWD
2：Run Reverse-REV
3：Jog FWD
4：Jog REV
5：Three Wire Control
6：Clear Fault
7：External Fault Input
1
◎
F5.02 DI2 Setting 2
◎
F5.03 DI3 Setting 9
◎
F5.04 DI4 Setting 12
◎
F5.05 HDI Setting 0
◎
- 118 -
