CHINT NVF5 Series User Manual

NVF5 Series User Manual Appendix B Parameter list
Code
Name
Setting Range
Default
Change
Time
F5.20 Reserve -- --
○
F5.21 AI1 Filter
（0.00 ～ 10.00）s
0.05s
○
F5.22 AI2 Filter
（0.00 ～ 10.00）
s
0.05s
○
F5.23 Reserve
--
--
○
F5.24 Curve Selection
Range:0x0000~0x0333
Ones Place ： AI1 Curve
Selection
0：Curve1
1：Curve 2
2：Curve 3
3：Curve 4
Tens Place ： AI2 Curve
Selection
0：Curve1
1：Curve2
2：Curve 3
3：Curve 4
Hundreds Place：Reserve
Thousandd Place：Reserve
0x0000
○
F5.25
Curve 1 Min.
Reference
0.00V ～ F5.27
0.00V
○
F5.26
Curve 1 Min.
Reference Setting
（-100.0 ～ +100.0）%
0.0%
○
F5.27
Curve 1 Max.
Reference
F5.25 ～ +11.00V
10.00V
○
F5.28
Curve 1 Max.
Reference Setting
（-100.0 ～ +100.0）%
100.0%
○
F5.29
Curve 2 Min.
Reference
0.00 ～ F5.31
0.00V
○
F5.30
Curve 2 Min.
Reference Setting
Same as F5.26 0.0%
○
F5.31
Curve 2 Max.
Reference
F5.29 ～ +11.00V
10.00V
○
F5.32
Curve 2 Max.
Reference Setting
Same as F5.26 100.0%
○
F5.33
Curve 3 Min.
Reference
-10.00V ～ F5.35
-10.00V
○
F5.34
Curve 3 Min.
Reference Setting
（-100.0 ~ +100.0）%
-100.0%
○
F5.35
Curve 3 Max.
Reference
F5.33～ +11.00V
10.00V
○
F5.36
Curve 3 Max.
Reference Setting
（-100.0 ~ +100.0）%
100.0%
○
F5.37
Curve 4 Min.
Reference
-10.0V～ F5.39
0.00V
○
F5.38
Curve 4 Min.
Reference Setting
（-100.0 ~ +100.0）%
0.0%
○
- 121 -
