CHINT NVF5 Series User Manual

NVF5 Series User Manual Chapter 6 Parameter Function Description
time, the output is effective.，Timer set by F8.33
35
AI1 〉 AI2 When AI1 〉 AI2 ，Output effective
36
Reserve
--
37
Current Running Time
Reach
When accumulate running time is exceed
F8.34- Current Running Reach Time ，Output
effective.
6.11.3 Analog Input Function（AI）
NVF5 Series has 2 Analog Input terminals -AI1、AI2，with -10V ～ +10V、4mA ～
20mA，AI2 can select V or mA signal by Dip switch on the PCB board.AI setting
mode,See Parameter“6.2.3 Analog Main Frequency Setting”.
6.11.4 Analog、Pulse Output Function（AO、HDO）
NVF5 Series has 1 AO，1 High Speed Pulse Output(HDO).
Code
Name
Default
Setting Range
Description
F6.00
HDO Output Type
0
0 ～ 1
See Below
Table
F6.08
AO1 Output Setting
Selection
0
0 ～ 36
F6.09
HDO Output Setting
Selection
0
0 ～ 36
F6.10
AO1 Zero Bias Correction
Factor
0.0%
（ -100.0 ～
100.0）%
F6.11
AO1 Gain
1.00
-10.0. ～ 10.00
F6.12
HDO Max. Output Pulse
Frequency
10.00kHz
（0.01 ～ 100.00）
kHz
AO、HDO Terminal Function Description：
Values
Function
Description
0
No Applicable
No Applicable
1
Running Frequency
0～Max. Output Frequency
2
Setting Frequency
0～Max. Output Frequency
3
Ramp Reference
Frequency
0～Max. Output Frequency
4
Output RPM
0～Max. RPM
5
Output Current1
0～2 times Inverter Rated Current
6
Output Current 2
0～2 times Motor Rated Current
7
Output Torque（Absolute） 0～3 times Motor Rated Torque
8
Output Power
0～2 2 times Motor Rated Power
9
Output Voltage
0～1.2 times Inverter Rated Voltage
- 84 -
