Freeze-dryer Alpha 1-4 LDplus
Freeze-dryer Alpha 2-4 LDplus
10 Technical data
Version 11/2006, Rev. 2.2 of 17/10/2016 • sb
67 / 102
Translation of the original operating manual
Pos: 203 /200 Chris t/361 GT-B A Labor-Pilot ( PROJEKTE)/Alp ha/Alpha 1- 4_2-4 LDplus/10 0 Technische D aten/100 Tech nische Date n Alpha 1-4/2-4 LD plus======= ======= ========= @ 35\ mod_1430380285 934_68.doc x @ 258914 @ 1 @ 1

10 Technical data
Manufacturer:
Martin Christ Gefriertrocknungsanlagen GmbH
An der Unteren Söse 50
37520 Osterode
Germany
Type:
Alpha 1-4 LDplus
Alpha 2-4 LDplus
Part number:
101541
101542
Performance data
Alpha 1-4 LDplus
Alpha 2-4 LDplus
Ice condenser
- capacity:
- performance:
- temperature:
- chamber volume:
4 kg max
4 kg / 24 h max
approx. –55°C
approx. 6.5 l
4 kg max
4 kg / 24 h max
approx. –85°C
approx. 6.5 l
Possible shelf temperatures
( single chamber method):
freezing and drying inside the ice
condenser chamber
approx. –20°C to +60°C
approx. –35°C to +60°C
Possible shelf temperatures
( double chamber method):
drying outside the ice condenser
chamber
Room temperature to +60°C
Room temperature to +60°C
Max. shelf surface area
(  double chamber method):
drying outside the ice condenser
chamber
drying in injection vials with
sealing under vacuum or nitrogen
atmosphere outside the ice
condenser chamber
drying in round bottom flasks
5 shelves, Ø 265 mm each
A
total
=0.28m
2
distance 79 mm
with accessory no. 120902
or
5 shelves,  360 mm each
A
total
=0.51 m
2
distance 70 mm
with accessory no. 120916
4 shelves,  250 mm each
A
total
=0.18 m
2
distance 50 mm
with accessory no. 121011
12 pieces or 24 pieces
10 shelves, Ø 200 mm each
A
total
=0.31m
2
distance 79 mm
with accessory no. 120902
or
5 shelves,  360 mm each
A
total
=0.51 m
2
distance 70 mm
with accessory no. 120916
4 shelves,  250 mm each
A
total
=0.18 m
2
distance 50 mm
with accessory no. 121011
12 pieces or 24 pieces
