Chroma 19032-P User Manual

Electrical Safety Analyzer 19032-P Quick Start Guide
30
3. After DUT is connected, press [Stop] [Test] to start test, meanwhile, GB
CONTACT counts down as Figure 4-7 shown.
TEST
MODE SOURCE LIMIT RES. OFFSET
01 GB 25.00
A
1
00.0
m
Ω
G
et Cs
P
AGE UP
P
A
GE DOWN
SCANNER-1
1 2 3 4 5 6 7 8
GB
GB CONTACT 2.3s
R
emote Lock
o
ffset
E
rror
Figure 4-7
4. After GB CONTACT counting down for three seconds (Start Wait
setting time), then process test as Figure 4-8 shown.
TEST
MODE SOURCE
L
IMIT
R
ES.
O
FFSET
01 GB 25.00
A
1
.
9
m
Ω
G
et Cs
P
AGE UP
P
AGE DOWN
SCANNER-1
1 2 3 4 5 6 7 8
GB
TEST TIME: 1.3s
R
emote Lock
o
ffset
E
rror
Figure 4-8
5. When the test is end, if it judged as PASS, the screen as Figure 4-9
shown.
