HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
16
OFST : When this area is highlighted, it means the main unit has
been zeroed the leakage current of test cable and test lead
currently.
ERR : When this area is highlighted, it means there is unclear
error in error queue.
Danger LED : The testing status indication LED. When LED is light,
the tester is under testing status. There is high voltage or
mass current on testing terminal. Don’t touch the testing
terminal at the same time.
PASS LED : When this LED is light, it means DUT judge as PASS
after testing.
FAIL LED : When this LED is light, it means DUT judge as FAIL after
testing and then cutting off the main unit output
immediately. This LED keeps on light until the main unit
be pressed [STOP] key.
Key Area
Power Switch : The switch provides AC power source which the
tester is needed.
STOP Key : Reset key, after pressing this key the main unit return to
standby testing status immediately. That is cutting
output and clear all of judgments simultaneously.
START Key : After pressing this key, the main unit is under testing
status. The testing terminal has output and each
judgment function starts simultaneously.
Cal-Enable : Calibration switch. This key is only for calibration
before exiting factory. A non-professional personnel
using this function is prohibited or may cause the product
malfunction.
Function Keys: Function key. Under different display menus, there are
different functions. The right side of display has
corresponding function description. If the description is
blank, it means corresponding function key is invalid.
Terminal Area
OUTPUT : High electric potential terminal of high voltage output.
This terminal is belong to high electric potential output,
usually is high voltage output. Therefore, this terminal
