HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
20
2. Move the highlighted to "SYSTEM" by Function Key UP, DOWN.
Press Function Key SELECT to enter system parameter setting menu
is shown as the following:
1. CONTRAST : 3
UP
2. BEEPER VOL. : HIGH
3. PASS ON : CONT.
DOWN
4. DC 50V AGC : OFF
ENTER
1-16 RMT LOCK OFST ERR
EXIT
3.4.2 Operation Method
1. After entering system parameter setting menu, press Function Key
ENTER to move the highlighted to the parameter item, which want to
set.
2. Press Function Keys UP, DOWN to set this item parameter data.
System parameter setting data description table
Setting
Item
Range Initial
Setting
Description
Contrast
1∼16
7 Adjust LCD brightness
Beeper Vol. LOW/MEDIUM/
HIGH/OFF
HIGH Adjust buzzer volume
PASS ON CONT. /0.1~99.9s CONT. It sets continuous time of
PASS signal on Remote I/O
interface of rear panel.
DC 50V
AGC
ON/OFF ON When it is set above DC
50V, hardware automatic
gain compensation function
is open or not.
