HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
27
LOW : 0.001mA
STEP 1 DC
ARC : OFF
DELETE
VOLT: 0.050kV RAMP : 999.0s
HIGH: 0.500mA FALL : OFF
INSERT
TIME: 3.0s CHK : OFF
DWLL: OFF 1 2 3 4 5 6 7 8
DOWN
SCAN : X X X X X X X X
PROCESS STEP RMT LOCK OFST ERR
MORE..
5. By using Function Keys DOWN to decrease test procedure which you
want to set, the range is 1∼99.
6. Press Function Keys DELETE, INSERT can delete, insert a test
procedure.
7. Press Function Key MORE.. can return to PROGRAM setting menu to
continue setting others test parameter.
3.7.2 Select Test Mode
1. After entering PROGRAM setting menu, press ENTER key to move the
highlighted cursor to the following position.
LOW : 0.001mA
STEP 1 DC
ARC : OFF
UP
VOLT: 0.050kV RAMP: 999.0s
HIGH: 0.500mA FALL : OFF
DOWN
TIME: 3.0s CHK : OFF
1 2 3 4 5 6 7 8
ENTER
SCAN: X X X X X X X X
SELECT MODE RMT LOCK OFST ERR
EXIT
2. Use Function Key UP, DOWN to select test mode. There are AC / DC
/ IR / OS / PA test modes can be selected (19051 only AC / DC / OS /
PA). Different test modes have different test parameters can be set.
