3.7.3 SMART KEY Operation Methods
1. When starts SMART KEY function of PRESET parameter in each test,
it records the test parameters. The test parameter includes: withstand
test needed voltage, the high limit value of leakage current, needed
test time, the low limit of leakage current, the high limit of electric arc,
needed rise time to setting voltage, the high limit of real leakage
current, scanning selection point. Each parameter can store ten sets
of value.
2. After entering PROGRAM setting screen, press ENTER key continuous
for one second then will show S-KEY word on the lower left side of
screen. At this time, the adjustment function of UP and DOWN keys is
disabled and read back the previous test parameter. If want to
recover the adjustment function of UP and DOWN keys, press ENTER
key continuous for one second until S-KEY word on the lower left side
of screen is disappeared.
3.7.4 Each Parameter Setting Data Description
The following described parameter setting data of each test mode.
AC withstand voltage test mode
LOW: 0.001mA
STEP 1 AC
ARC : OFF
UP
VOLT: 0.050kV RAMP: 999.0s
HIGH: 0.500mA FALL: OFF
DOWN
TIME: 3.0s REAL: OFF
1 2 3 4 5 6 7 8
ENTER
SCAN: X X X X X X X X
SELECT MODE RMT LOCK OFST ERR
EXIT
VOLT: It sets withstand voltage test needed voltage.
HIGH: It sets leakage current high limit value.
TIME : It sets test needed time, input 0 means continuous test.
LOW : It sets leakage current low limit value, input 0 means OFF.
ARC: It sets arc high limit, input 0 means OFF.
RAMP: Step-up setting voltage needed time, input 0 means OFF.
