HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
29
FALL : The needed time is from setting voltage value to zero, 0 means OFF.
REAL: It sets real leakage current high limit value, input 0 means OFF.
SCAN: It sets scan test selection point.
DC withstand voltage test mode
LOW : 0.001mA
STEP 1 DC
ARC : OFF
UP
VOLT: 0.050kV RAMP: 999.0s
HIGH: 0.500mA FALL : OFF
DOWN
TIME: 3.0s CHK : OFF
DWLL: OFF 1 2 3 4 5 6 7 8
ENTER
SCAN: X X X X X X X X
SELECT MODE RMT LOCK OFST ERR
EXIT
VOLT: It sets withstand voltage test needed voltage.
HIGH: It sets leakage current high limit value.
TIME: It sets test needed time, input 0 means continuous test.
DWLL: It sets DWELL needed time, 0 means OFF.
(During DWELL TIME action don’t judge high and low limit value of
leakage current but the limit don’t over high limit of setting range.)
LOW : It sets leakage current low limit value, input 0 means OFF.
ARC: It sets arc high limit, input 0 means OFF.
RAMP: Step-up setting voltage needed time, input 0 means OFF.
FALL: The needed time is from setting voltage value to zero, 0 means OFF.
CHK: It selects detect charge current over low (CHECK LOW)
SCAN: It sets scan test selection point.
IR Insulation resistance test mode
HIGH : OFF
STEP 1 IR
RAMP: OFF
UP
VOLT : 0.050kV FALL : OFF
LOW : 1.0MΩ RNG : AUTO
DOWN
TIME : 3.0s 1 2 3 4 5 6 7 8
SCAN: X X X X X X X X
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
