Chroma 19051 - Page 44

HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
30
VOLT: It sets insulation resistance test needed voltage.
LOW: It sets insulation resistance low limit value.
TIME: It sets test needed time, input 0 means continuous test.
HIGH: It sets insulation resistance high limit value, input 0 means OFF.
RAMP: Step-up setting voltage needed time, input 0 means OFF.
FALL: The needed time is from setting voltage value to zero, 0 means OFF.
RNG: It sets the current test range of insulation resistance, AUTO means
automatic switch range. The relation of current range and
resistance measurement range is as below table shown.
IR Display Value
Range
Setting Voltage
50V ~ 250V
Setting Voltage
250V ~ 1000V
10mA(3~10mA)
0.10MΩ~0.10MΩ 0.10MΩ~1.00MΩ
3mA(0.3~3mA) 0.10MΩ~0.90MΩ 0.10MΩ~3.50MΩ
300uA(30~300uA)
0.10MΩ~9.00MΩ 0.10MΩ~25.00MΩ
22.0MΩ~35.0MΩ
30uA(3~30uA)
0.10MΩ~25.00MΩ
22.0MΩ~90.0MΩ
0.10MΩ~25.00MΩ
22.0MΩ~250.0MΩ
0.220GΩ~0.350GΩ
3uA(0.3~3uA)
22.0MΩ~250.0MΩ
0.220GΩ~0.900GΩ
25.0MΩ~250.0MΩ
0.220GΩ~2.500GΩ
2.20GΩ~3.33GΩ
300nA(20~300nA)
0.200GΩ~2.000GΩ 0.200GΩ~2.500GΩ
2.20GΩ~50.00GΩ
Note
Select IR suitable current range please follows test voltage and
DUT insulation resistance for counting the quantity of current then
follows it to select suitable current range.
SCAN: It sets scan test selection point.
