HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
31
Short/Open Circuit detection test mode (OS)
OPEN CHK : 50%
STEP 1 OS
SHORT CHK : 300%
UP
1 2 3 4 5 6 7 8
SCAN: X X X X X X X X
DOWN
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
OPEN CHK: It sets the judgment test result to open condition(compare the
test reading with the read standard capacitance value [Cs]).
SHORT CHK: It sets the judgment test result to short condition(compare
the test reading with the read standard capacitance value
[Cs]).
SCAN: It sets the scanning test selection point.
Pause Mode
STEP 1 PA
UP
MESSAGE : PAUSE MODE
UNDER TEST SIGNAL : OFF
DOWN
TIME : CONT.
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
MESSAGE: It sets the message shows on pause screen, the maximum
input character is 15.
UNDER TEST SIGNAL: It sets UNDER TEST signal on rear panel when
pause and DANGER LED action.
(1) It sets to ON: UNDER TEST terminal on rear panel is short
circuit under pause mode. DANGER LED on panel is
blinking.
(2) It sets to OFF: UNDER TEST terminal on rear panel is open
