Chroma 19051 User Manual

HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
2
1.2 Specifications (18°C ∼ 28°C RH ≤ 70%)
 Scan Unit
8 ports, ⋅ ±phase (19053 only), 4 ports, ⋅ ±phase
(19054 only)
 Withstanding Voltage Test
 Test Voltage
AC: 0.05 ∼ 5kV/ DC: 0.05 ∼ 6kV Constant Voltage
 Voltage
Regulation
≤ (1%+5V), Rated Load
 V-display
Accuracy
± (1% of reading + 5 counts), 2V resolution
 Cutoff Current
(Note 2)
AC: 0.1mA ~ 30mA (Note 1), DC: 0.01mA ~ 10mA
(Note 1), 0.1uAdc resolution
 Current Accuracy
(Note2)
± (1% of reading + 5 counts)
Real Current ± (5% of total current + 20 counts)
(Note2) WAC only
 Current Display
Hi limit setting Display Range
< 300uA: 0.1uA~299.9uA (dc only)
< 3mA: 0.001mA~2.999mA
<30mAac (10mAdc): 0.01mA~30.00mAac
(10mAdc)
 Output Frequency 50Hz, 60Hz
 Test Time (Note
3)
0.3 ~ 999 Sec, continue (Note 1) (0.2S for LCD off)
 Ramp Time 0.1 ~ 999 Sec, off (Note 1)
 Fall Time
0.1 ∼ 999 Sec, off
 Judgment Delay
(Wdc Only)
0.1 ~ 99.9 Sec. (Note 1)
 Arc Detection (Note 4)
 Setting Mode Programmable Setting
 Detection Current AC: 1mA ~ 15mA, DC: 1mA ~ 10mA
 Min. pulse width 10us approx.
 GOOD/NO-GO Judgment Function
 Judgment System
• Window comparator.
• A NO-GO judgment is made when a current
greater than the high limit value or smaller than
the low limit value is detected.
• When a NO-GO judgment is made, the output
voltage is cut out and a NO-GO alarm signal is
delivered.
• If no abnormal state is detected during the test
time a GOOD judgment is made and a GOOD
signal is delivered.
