High Power DC Electronic Load 63200 Series Operation & Programming Manual
Model 63207 63208 63209
Power*1 1040W 10400W 1560W 15600W 1560W 15600W
Current 0-30A 0-300A 0-60A 0-600A 0-100A 0-1000A
Voltage 1-80V 1-80V 1-80V
Min. operating voltage 1V @ 30A 1V @ 300A 1V @ 60A 1V @ 600A 1V @ 100A 1V @ 1000A
Constant Current mode
Range 0-30A 0-300A 0-60A 0-600A 0-100A 0-1000A
Resolution 9.3mA 75mA 15mA 150mA 31.25mA 250mA
Accuracy 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS 0.1%+0.2%FS
Constant Resistance mode
Range 0.005-20ohm 0.25-1000ohm 0.0025-10ohm 0.125-500ohm 0.0015-6ohm 0.075-300ohm
Resolution 12 bits 12 bits 12 bits 12 bits 12 bits 12 bits
Accuracy*2 0.6mho+0.35% 0.9mho+0.1%
1.2mho+0.35% *4
1.2mho+0.1%
1.2mho+0.35% *4
1.2mho+0.1%
Accuracy*3 (Vin>7V) 0.6mho+0.35% 0.012mho+0.35% 1.2mho+0.35% 0.024mho+0.35% 1.2mho+0.35% 0.024mho+0.35%
Constant Voltage mode
Range 1-16V 1-80V 1-16V 1-80V 1-16V 1-80V
Resolution 4mV 20mV 4mV 20mV 4mV 20mV
Accuracy 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS 0.05%+0.1%FS
Constant Power mode
Range 0.744-1040W 6-10400W 1.2-1560W 12-15600W 2.5-1560W 20-15600W
Resolution 9.3mW 75mW 22.5mW 225mW 31.255mW 250mW
Accuracy 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS 0.5%+0.5%FS
Dynamic mode
Timing
T1&T2 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S
Resolution 1uS 1mS 1uS 1mS 1uS 1mS
Accuracy 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm 1uS+100ppm 1mS+100ppm
Slew rate 6mA-1.5A/uS 50mA-12.5A/uS 12mA-3A/uS 100mA-25A/uS 20mA-5A/uS 166mA-41.6A/uS
Resolution 6mA/uS 50mA/uS 12mA/uS 100mA/uS 20mA/uS 166mA/uS
Current
Range 0-30A 0-300A 0-60A 0-600A 0-100A 0-1000A
Resolution 9.37mA 75mA 15mA 150mA 31.25mA 250mA
Accuracy 0.4%FS 0.4%FS 0.4%FS
Measurement
Voltage read back
Range 0-16V 0-80V 0-16V 0-80V 0-16V 0-80V
Resolution 15 bits 15 bits 15 bits 15 bits 15 bits 15 bits
Accuracy 0.05%+0.05%FS 0.05%+0.05%FS 0.05%+0.05%FS
