Chroma 66203 User Manual

Specification
2-1
2. Specification
2.1 Standard Specification
Functions
Model 66203 66204
Channel 3 Channel 4 Channel
Measurement
Parameters
Vrms, Vpk+, Vpk-, VTHD, Irms, Ipk+, Ipk-, ATHD, Is, CFi, W, VA,
VAR, PF, F, Energy
Input
Measurement Ranges
Voltage
Measurement
Ranges (rms)
15V/30V/60V/150V/300V/600V/Auto
The crest factor of all measurement ranges is 2.
Internal current sensor
0.005A/0.02A/0.05A/0.2A/0.5A/2A/5A/20A/Auto, when shunt range is
auto.
0.005A/0.02A/0.05A/0.2A/Auto, when shunt range is low.
0.5A/2A/5A/20A/Auto, when shunt range is high.
The crest factor of all measurement ranges is 4.
External current sensor
Current
Measurement
Ranges (rms)
10mV/25mV/50mV/100mV/Auto
The crest factor of all measurement ranges is 4.
Power Measurement
Ranges
75mW/…/12KW, 48 ranges
Input Impedance
Voltage
Measurement
Range
Approx. 2MΩ
Current
Measurement
Ranges
Approx. 500mΩ (Low Shunt Range)
Approx. 20mΩ (High Shunt Range)
External
Measurement Range
Approx. 100kΩ
Bandwidth
Approx. 60kHz
Protection
Over Voltage
Range(OUR)
When the measured value exceeds “Voltage Range × CF”
Over Current
Range(OCR)
When the measured value exceeds “Current Range × CF”
Over Current
Protection (OCP)
OCP will occur when the following measured current conditions are
exceeded.
1. 1.1Arms for low shunt range
2. 23Arms or 80Apeak for high shunt range
3. Burnt out of the 25A fast acting fuse (the current measurement
loop will become open circuit)
