Chromalox 6050 User Manual

53
Parameter
Lower
Display
Upper Display
Adjustment Range Default Value
When
Visible
Setpoint Upper Limit
SPuL
Current Setpoint value to Scale
Range Maximum
Range
Maximum
Always
Setpoint Lower limit
SPLL
Scale Range Minimum to current
Setpoint value
Range
Minimum
Always
Primary (Heat) Output
Upper Power Limit
OPuL
0% to 100% of full power
100 Pb_P is not 0.0
Output 1 Cycle Time
Ct1
0.5, 1, 2, 4, 8, 16, 32, 64, 128, 256
or 512 secs. Not applicable to
linear outputs
32 Use1 = Pri
or SEc
or buS
Output 2 Cycle Time
Ct2
0.5, 1, 2, 4, 8, 16, 32, 64, 128, 256
or 512 secs. Not applicable to
linear outputs
32 Use2 = Pri
or SEc
or buS
Output 3 Cycle Time
Ct3
0.5, 1, 2, 4, 8, 16, 32, 64, 128, 256
or 512 secs. Not applicable to
linear outputs
32 Use3 = Pri
or SEc
or buS
Process High Alarm 1
value*
PhA1
Range Min. to Range Max. Range
Maximum
ALA1 = P_Hi
Process Low Alarm 1
value*
PLA1
Range Min. to Range Max. Range
Minimum
ALA1 = P_Lo
Deviation Alarm 1
Value*
dAL1
±span from setpoint
5 ALA1 = de
Band Alarm 1 value*
bAL1
1 LSD to full span from setpoint.
5 ALA1 = bAnd
Alarm 1 Hysteresis*
AHy1
Up to 100% of span
1
Always
Process High Alarm 2
value*
PhA2
Range Min. to Range Max. Range
Maximum
ALA2 = P_Hi
Process Low Alarm 2
value*
PLA2
Range Min. to Range Max. Range
Minimum
ALA2 = P_Lo
Deviation Alarm 2 Value
dAL2
±span from setpoint
5 ALA2 = de
Band Alarm 2 value*
bAL2
1 LSD to full span from setpoint.
5 ALA2 = bAnd
Alarm 2 Hysteresis*
AHY2
Up to 100% of span
1
Always
Loop Alarm Time*
LAti
1 sec to 99 mins. 59secs. Only
applies if primary proportional
band = 0
99.59 LAEn = EnAb
Auto Pre-tune enable /
disable
APt diSA disabled or
EnAb enabled
diSA
Always
Manual Control select
enable / disable
PoEn diSA disabled or
EnAb enabled
diSA
Always
Setpoint Select shown
in Operator Mode, en-
able / disable
SSEn diSA disabled or
EnAb enabled
diSA
Slot A or B fitted
with RSP module
Setpoint ramp shown in
operator mode, enable
/ disable
SPr diSA disabled or
EnAb enabled
diSA
Always
SP Ramp Rate Value
rP
1 to 9999 units/hour or Off (blank) Blank Always
Setpoint Incremental
Value
SPin
0 to +input span 1
Programmable Sensor
Break
PSb
diSA (disabled) or EnAb (enabled) EnAb
Preset Power Output
PPo
0%(-100% if dual control) to 100% 0
Heater Current High
Scale Limit
htrH
0.0 to 100.0 0.0
Low Heater Break
Alarm Value
L_hb
0 to Heater Current High Scale
Limit
0.0
