Chromalox 6050 User Manual

81
Figure 41
Alarm Hysteresis Operation
PROCESS
HIGH ALARM
PROCESS
LOW ALARM
BAND ALARM
DEVIATION
HIGH ALARM
DEVIATION
LOW ALARM
Inactive
Inactive
Inactive
Inactive
Inactive
Inactive
Alarm Inactive Alarm Inactive
Alarm Active
Active
Inactive
Inactive
Active
Active
Inactive
Active
Active
Alarm Value
Alarm Value
Alarm Value
(from Setpoint)
Setpoint
Process Variable
Process Variable
Process Variable
Process Variable
Process Variable
Alarm Hysteresis Value
Alarm Hysteresis Value
Alarm Hysteresis Value
Alarm Hysteresis Value
Alarm Hysteresis Value
Alarm Hysteresis Value
Setpoint
Setpoint
Alarm Value
(from Setpoint)
Alarm Value
(from Setpoint)
Alarm Value
(from Setpoint)
Alarm Hysteresis
Type: General Parameter
An adjustable band on the “safe” side of an alarm point,
through which the process variable must pass before
the alarm will change state, as shown in the diagram
below. E.g. a high alarm’s hysteresis band is below the
high alarm value, and a low alarm’s hysteresis is above
the low alarm value.
Also refer to Alarm Operation.
