14. Configuration and Programming
14.1 C-PWR Configuration Software Program
See C-PWR Configuration Software Program instruction manual for proper program installation.
14.2 C4/C4X/C4-IR Programming Manual
See C4/C4X/C4-IR Programming Manual for complete controller set-up of communications, inputs, outputs,
alarms and control modes.
15. Accessories
15.1 Fuses and Fuse Holders
C4 Model
I
2
T Extra Rapid Fuses Fuse Holder
Fuse Rating,
Amps I
2
T
Power
Dissipation Fuse Size
Manufacturer’s
Model Code Part No. Part No.
Fuse Holder
Rating (UL)
C4-164 16A 645A
2
s 3.5W 10x38 FUS-016 0024-07824 0024-12124 30A@600V
C4-304 30A 1010A
2
s 4.8W 10x38 FUS-030 0024-07825 0024-12124 30A@600V
15.2 Fieldbus Cards
Fieldbus Type Part No.
Model No.
(Fieldbus
Card)
Manufacturer’s
Model Code Description
Modbus RTU 0149-50103 C4-MOD F032357 Card for Modbus RTU protocol (serial 2)
Profibus DP 0149-50104 C4-PROFI F032358 Card for Profibus DP protocol (serial 2)
CANopen 0149-50105 C4-CAN F032359 Card for CANopen protocol (serial 2)
DeviceNet 0149-50106 C4-DNET F032360 Card for DeviceNet protocol (serial 2)
Modbus TCP/IP 0149-50107 C4-ETH F033532 Card for Ethernet Modbus TCP protocol (serial 2)
EtherCat 0149-50108 C4-ETH2 F049411 Card for EtherCat protocol (serial 2)
Profinet 0149-50109 C4-ETH4 F054949 Card for Profinet protocol (serial 2)
Ethernet IP (Real-Time) 0149-50110 C4-ETH5 F058234 Card for Real Time Ethernet/IP protocol
Additional Spare Parts
Part No.
Manufacturer’s
Model Code Description
0149-50099 F032861 Connection cable for serial Modbus (RJ10) 0.3M
0149-50100 F032862 Connection cable for serial Modbus (RJ10) 1M
0149-50101 F032863 Connection cable for serial Modbus (RJ10) 2M
0149-50102 F032864 Connection cable for serial Modbus (RJ10) 5M
0149-50111 VEN-61 Fan (flow 39m3/h) for C4-164
0149-50112 VEN-62 Fan (flow 56m3/h) for C4-304 and C4-404
0149-50113 GRI-4 Grill fan for C4
0149-50114 FLT-4 Filter for fan
0149-50115 COUT4-9 9-Terminal Connector (J1) For C4 Controller
0149-50116 COUT4-4 4-Terminal Connector (J1a) For C4 Controller
0149-50117 CSIG4-7 7-Terminal Connector (J2) For C4 Controller
0149-50118 CSIG4-12 12-Terminal Connector (J4) For C4 Controller
0149-50119 CSIG4-4 4-Terminal Connector (J3a) For C4 Controller
