SUSPENSION
Front Axle
ZF RL75E (2016)
RL85E (2017)
Double A-shaped beam axle, airbag suspension, two leveling valves
with two airbags, two telescopic shock absorbers and lateral stabilizer.
Front wheel orientation: Wheel camber 0.5º - 1º. Approaching 1º is
recommended. The angle difference should not exceed 0.3º on both
sides.
Kingpin inclination . . . . . . . . . . . . . . . . . . .7.5º+/- 0.5º
Castor . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.30º
Toe-in . . . . . . . . . . . . . . . . . . . . . . . . . . . .0mm +/-1mm
Driving Axle
ZF A132
Integrated press-welding axle housing, full-floating axle shaft, single
reduction final drive hyperbolic gear.
Final gear ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.27/1
All airbag suspension, two leveling valves with four airbags, four
telescopic shock absorbers and lateral stabilizer.
Tag Axle
ZF RL85A TAP
Integrated I-shaped beam, with adapted steering control. Airbag
suspension, two airbags, two telescopic shock absorbers and air
pressed control braking system disc brake.
STEERING SYSYTEM
Power Steering
ZF8098
Recirculating ball-type power steering system.
WHEELS AND TIRES
Wheel type Hub Pilot Alcoa
®
wheels.
Tire specifications (front and rear) . . . . . Michelin 315/80R22.5
BRAKING SYSTEM
Dual-circuit air braking ABS and self-correcting adjusting arm. Air
pressure servo assist with identical disc brakes at all wheels. Manual
valve operated parking brake, energy storage spring works on rear
brake.
Emergency brake effected with parking brake.
