CONTROLS
21
Motor Coach Climate Controller During vehicle maintenance, service personnel can enter diagnostic
mode by pressing preset sequence of buttons or using optional MCC
Coolview via CANBus connection. In this mode, errors stored in
memory and real-time data of inputs and outputs are displayed for
easy trouble shooting
.
Table 7: Motor Coach Climate Controller
Number
Item
1
Temperature Set-point
Adjust temperature for passenger compartment
2
On/Off Button
Turn HVAC system On or Off
3
Cursor
Cursor and mode selection
4
Information
Display system information
