CIAT AeroCONNECT 1B - Page 38

EN7510364-00 EN - 36
No.
PARAMETER NAME PARAMETER ADJUSTMENT
Notes
Description Display conditions Adjustment possible
By
default
Adjustment
conditions
A153
STAGE 2 DIFFERENCE A02 = 1 and A03 = 1 and A08 ≥ 3
1 to 5°C
(increments of 1)
2
If A03 = 1 or 2
water circuits
STAGE 3 COIL 1 DIFFERENCE A02 = 2 and A03 = 1 and A08 ≥ 3
STAGE 3 CIRCUIT 1
DIFFERENCE
A02 = 1 and A03 = 2 and A08 ≥ 3
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuits
STAGE 3 COIL.1 CIR.1
DIFFERENCE
A02 = 2 and A03 = 2 and A08 ≥ 3
A154
STAGE 3 HYSTERESIS
A02 = 1 and A03 = 1 and
A08 ≥ 3
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 3 COIL 1
A02 = 2 and A03 = 1 and
A08 ≥ 3
HYST. STAGE 3 CIRCUIT 1
A02 = 1 and A03 = 2 and
A08 ≥ 3
2 to 6 bar
(increments of 0.5)
3.5
If A03 = 1 or 2
refrig. circuits
HYST. STAGE 3 COIL.1 CIR.1
A02 = 2 and A03 = 2 and
A08 ≥ 3
A155
STAGE 3 DIFFERENCE
A02 = 1 and A03 = 1 and
A08 ≥ 4
1 to 5°C
(increments of 1)
2
If A03 = 1 or 2
water circuits
STAGE 4 COIL 1 DIFFERENCE
A02 = 2 and A03 = 1 and
A08 ≥ 4
STAGE 4 CIRCUIT 1
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 4
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuits
STAGE 4 COIL.1 CIR.1
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 4
A156
STAGE 4 HYSTERESIS
A02 = 1 and A03 = 1 and
A08 ≥ 4
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 4 COIL 1
A02 = 2 and A03 = 1 and
A08 ≥ 4
HYST. STAGE 4 CIRCUIT 1
A02 = 1 and A03 = 2 and
A08 ≥ 4
2 to 6 bar
(increments of 0.5)
3.5
If A03 = 1 or 2
refrig. circuits
HYST. STAGE 4 COIL.1 CIR.1 A02 = 2 and A03 = 2 and A08 ≥ 4
A157
STAGE 5 DIFFERENCE
A02 = 1 and A03 = 1 and
A08 ≥ 5
1 to 5°C
(increments of 1)
2
If A03 = 1 or 2
water circuits
STAGE 5 COIL 1 DIFFERENCE
A02 = 2 and A03 = 1 and
A08 ≥ 5
STAGE 5 CIRCUIT 1
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 5
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuits
STAGE 5 COIL.1 CIR.1
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 5
A158
STAGE 5 HYSTERESIS
A02 = 1 and A03 = 1 and
A08 ≥ 5
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 5 COIL 1
A02 = 2 and A03 = 1 and
A08 ≥ 5
HYST. STAGE 5 CIRCUIT 1
A02 = 1 and A03 = 2 and
A08 ≥ 5
2 to 6 bar
(increments of 0.5)
3.5
If A03 = 1 or 2
refrig. circuits
HYST. STAGE 5 COIL.1 CIR.1
A02 = 2 and A03 = 2 and
A08 ≥ 5
A159
STAGE 6 DIFFERENCE
A02 = 1 and A03 = 1 and
A08 ≥ 6
1 to 5°C
(increments of 1)
2
If A03 = 1 or 2
water circuits
STAGE 6 COIL 1 DIFFERENCE
A02 = 2 and A03 = 1 and
A08 ≥ 6
STAGE 6 CIRCUIT 1
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 6
0.5 to 3 bar (0.5 increments) 0.5
If A03 = 1 or 2
refrig. circuits
STAGE 6 COIL.1 CIR.1
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 6
A160
STAGE 6 HYSTERESIS
A02 = 1 and A03 = 1 and
A08 ≥ 6
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 6 COIL 1
A02 = 2 and A03 = 1 and
A08 ≥ 6
HYST. STAGE 6 CIRCUIT 1
A02 = 1 and A03 = 2 and
A08 ≥ 6
2 to 6 bar
(increments of 0.5)
3.5
If A03 = 1 or 2
refrig. circuits
HYST. STAGE 6 COIL.1 CIR.1
A02 = 2 and A03 = 2 and
A08 ≥ 6
A160.1
STAGE 7 DIFFERENCE A02 = 1 and A03 = 1 and A08 ≥ 7 1 to 5°C (in increments of 1) 2
If A03 = 1 or 2
water circuits
STAGE 7 COIL 1 DIFFERENCE A02 = 2 and A03 = 1 and A08 ≥ 7 0.5 to 3 bar (0.5 increments) 0.5
If A03 = 1 or 2
refrig. circuits
A160.2
STAGE 7 HYSTERESIS A02 = 1 and A03 = 1 and A08 ≥ 7
1 to 10°C (in increments
of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 7 COIL 1 A02 = 2 and A03 = 1 and A08 ≥ 7 0.5 to 3 bar (0.5 increments) 0.5
If A03 = 1 or 2
refrig. circuits
