CIAT AeroCONNECT 1B - Page 39

EN
EN - 37 EN7510364-00
No.
PARAMETER NAME PARAMETER ADJUSTMENT
Notes
Description Display conditions
Adjustment
possible
By default
Adjustment
conditions
A161
HYST. STAGE 1 CIRCUIT 2 A02 = 1 and A03 = 2
1 to 20°C (in
increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 1 COIL.1 CIR.2 A02 = 2 and A03 = 2
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
refrig. circuits
A162
STAGE 2 CIRCUIT 2
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 2
0.5 to 3 bar (0.5
increments)
2
If A03 = 1 or 2
water circuits
STAGE 2 COIL.1 CIR.2
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 2
0.5 to 3 bar (0.5
increments)
0.5
If A03 = 1 or 2
refrig. circuits
A163
HYST. STAGE 2 CIRCUIT 2
A02 = 1 and A03 = 2 and
A08 ≥ 2
1 to 10°C 5
If A03 = 1 or 2
water circuit
On/Off control ONLY with
CONDENSER and DRYCOOLER
before version V07
HYST. STAGE 2 COIL.1 CIR.2
A02 = 2 and A03 = 2 and
A08 ≥ 2
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
water circuits
A164
STAGE 3 CIRCUIT 2
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 3
1 to 5°C (in increments
of 1)
2
If A03 = 1 or 2
water circuit
STAGE 3 COIL.1 CIR.2
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 3
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuit
A165
HYST. STAGE 3 CIRCUIT 2
A02 = 1 and A03 = 2 and
A08 ≥ 3
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuits
HYST. STAGE 3 COIL.1 CIR.2
A02 = 2 and A03 = 2 and
A08 ≥ 3
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
refrig. circuit
A166
STAGE 4 CIRCUIT 2
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 4
1 to 5°C (in increments
of 1)
2
If A03 = 1 or 2
water circuit
STAGE 4 COIL.1 CIR.2
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 4
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuit
A167
HYST. STAGE 4 CIRCUIT 2
A02 = 1 and A03 = 2 and
A08 ≥ 4
1 to 10°C
(increments of 0.5)
5
If A03 = 1 or 2
water circuit
HYST. STAGE 4 COIL.1 CIR.2
A02 = 2 and A03 = 2 and
A08 ≥ 4
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
refrig. circuit
A168
STAGE 5 CIRCUIT 2
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 5
1 to 10°C
(increments of 1)
2
If A03 = 1 or 2
water circuit
STAGE 5 COIL.1 CIR.2
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 5
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuit
A169
HYST. STAGE 5 CIRCUIT 2
A02 = 1 and A03 = 2 and
A08 ≥ 5
1 to 10°C
(increments of 1)
5
If A03 = 1 or 2
water circuit
HYST. STAGE 5 COIL.1 CIR.2
A02 = 2 and A03 = 2 and
A08 ≥ 5
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
refrig. circuit
A170
STAGE 6 CIRCUIT 2
DIFFERENCE
A02 = 1 and A03 = 2 and
A08 ≥ 6
1 to 5°C (in increments
of 1)
2
If A03 = 1 or 2
water circuit
STAGE 6 COIL.1 CIR.2
DIFFERENCE
A02 = 2 and A03 = 2 and
A08 ≥ 6
0.5 to 3 bar
(increments of 0.5)
0.5
If A03 = 1 or 2
refrig. circuit
A171
HYST. STAGE 6 CIRCUIT 2
A02 = 1 and A03 = 2 and
A08 ≥ 6
1 to 10°C
(increments of 1)
5
If A03 = 1 or 2
water circuit
HYST. STAGE 6 COIL.1 CIR.2
A02 = 1 and A03 = 2 and
A08 ≥ 6
2 to 6 bar (0.5
increments)
3.5
If A03 = 1 or 2
refrig. circuit
A172
HYST. STAGE 1 COIL 2 A02 = 2 and A05 = 1
1 to 20°C
(increments of 0.5)
5
If A05 = 1 or 2
water circuit
HYST. STAGE 1 COIL.2 CIR.1 A02 = 2 and A05 = 2
2 to 6 bar (0.5
increments)
3.5
If A05 = 1 or 2
refrig. circuit
A173
STAGE 2 COIL 2
DIFFERENCE
A02 = 2 and A05 = 1 and
A08 ≥ 2
1 to 5°C (in increments
of 1)
2
If A05 = 1 or 2
water circuit
STAGE 2 COIL.2 CIR.1
DIFFERENCE
A02 = 2 and A05 = 2 and
A08 ≥ 2
0.5 to 3 bar
(increments of 0.5)
0.5
If A05 = 1 or 2
refrig. circuit
A174
HYST. STAGE 2 COIL 2
A02 = 2 and A05 = 1 and
A08 ≥ 2
1 to 10°C
(increments of 1)
5
If A05 = 1 or 2
water circuit
HYST. STAGE 2 COIL.2 CIR.1
A02 = 2 and A05 = 2 and
A08 ≥ 2
2 to 6 bar (0.5
increments)
3.5
If A05 = 1 or 2
refrig. circuit
A175
STAGE 3 COIL 2
DIFFERENCE
A02 = 2 and A05 = 1 and
A08 ≥ 3
1 to 5°C (in increments
of 1)
2
If A05 = 1 or 2
water circuit
STAGE 3 COIL.2 CIR.1
DIFFERENCE
A02 = 2 and A05 = 2 and
A08 ≥ 3
0.5 to 3 bar
(increments of 0.5)
0.5
If A05 = 1 or 2
refrig. circuit
A176
HYST. STAGE 3 COIL 2
A02 = 2 and A05 = 1 and
A08 ≥ 3
1 to 10°C
(increments of 1)
5
If A05 = 1 or 2
water circuit
HYST. STAGE 3 COIL.2 CIR.1
A02 = 2 and A05 = 1 and
A08 ≥ 3
2 to 6 bar (0.5
increments)
3.5
If A05 = 1 or 2
refrig. circuit
A177
STAGE 4 COIL 2
DIFFERENCE
A02 = 2 and A05 = 1 and
A08 ≥ 4
1 to 5°C (in increments
of 1)
2
If A05 = 1 or 2
water circuit
STAGE 4 COIL.2 CIR.1
DIFFERENCE
A02 = 2 and A05 = 2 and
A08 ≥ 4
0.5 to 3 bar
(increments of 0.5)
0.5
If A05 = 1 or 2
refrig. circuit
