CIAT XtraConnect 2 - Page 17

EN - 16
Access
level
No. Description Setting Default Display conditions
Operation (continued)
1
276.2 Electricity (module 1) If P3 = 3 and P15 = Yes
1
276.3 Electricity (module 2) If P3 = 3 and P15 = Yes
1
285 Runtime in heating mode
If P119  Cooling
1
286 Runtime in cooling mode
If P119  Heating
1
287 Pump 1 runtime (in hours)
1
288 Pump 2 runtime (in hours)
1
289 No. of times P99 set to "No"
1 290 Number of water flow cut-offs in 1 hour Visible in cooling mode
Circuit 1
1
300 Circuit 1 HP
1
300.1 Circuit 1 HP control setpoint If P2 = Air-to-water and P3 = 1 or 2
1
301 Circuit 1 condensing temperature See appendix
1
302.1 Discharge temperature 1
1
303.1 Desuperheat on discharge 1 P302.1 - P 301
1
304 Circuit 1 LP
1
305 Circuit 1 evaporating temperature See appendix
1
306 Circuit 1 suction temperature (°C)
1
307 Circuit 1 superheat (°C)
1
309 No. of LP1 cut-outs in 24 hours
1
316 No. of circuit 1 start-ups
1
317 Circuit 1 runtime (in hours)
1
318 Circuit 1 short-cycle protection
1
324.1 No. of discharge 1 temp. cut-outs in 24 h
1
326 Circuit 1 liquid temperature (°C) If P2 = 1 or 2 or (3 + cooling mode)
1
327 Circuit 1 subcooling (°C) If P2 = 1 or 2 or (3 + cooling mode)
Circuit 2
1
330 Circuit 2 HP If P2 = Air-to-water and P3 = 2
1
330.1 Circuit 2 HP control setpoint
If P3 = 2 and ≠Intertwined
1
331 Circuit 2 condensing temperature See appendix If P3 = 2
1
332.1 Discharge temperature 2 (°C)
1
333.1 Desuperheat on discharge 2 P332.1 - P 331
1
334 Circuit 2 LP If P3 = 2
1
335 Circuit 2 evaporating temperature See appendix If P3 = 2
1
336 Circuit 2 suction temperature (°C) P3 = 2
1
337 Circuit 2 superheat (°C) P3 = 2
1
339 No. of LP2 cut-outs in 24 hours If P3 = 2
1
346 No. of circuit 2 start-ups
1
347 No. of circuit 2 runtime (in hours)
1
348 Circuit 2 short-cycle protection
1
354
No. of circuit 2 discharge temperature cut-
outs in 24 hours
1
354.1
No. of discharge 2 temperature cut-outs in
24 hours
1
356 Circuit 2 liquid temperature (°C)
1
357 Circuit 2 subcooling (°C)
Circuit 3 display
1
360 Circuit 3 HP If P2 = Air-to-water and P3 = 3
1
361 Circuit 3 condensing temperature If P3 = 3
1
362 Circuit 3 discharge temperature If P3 = 3
1
363 Circuit 3 discharge desuperheat P363 - P362 If P3 = 3
1
364 Circuit 3 LP If P3 = 3
1
365 Circuit 3 evaporating temperature If P3 = 3
1
366 Circuit 3 suction temperature If P3 = 3
1
367 Circuit 3 superheat P366 - P365 If P3 = 3
