EN - 56
- If at least one time range or one holiday band is enabled, the machine stop or temp./setpoint message alternates with a message informing the
user that the state will be updated on the next time range state change. Each message is displayed for 3 seconds.
Message displayed:
Access:
Via menu 9: "9 SCHEDULING"
- Pressing OK will cause the TIME SCHEDULES and HOLIDAY BANDS submenus to appear
Select the desired submenu with the + and – buttons then press OK.
Cursor position:
- Located at the top left when moving through the various menus.
- Located at the bottom right just before the last character when adjusting the settings.
- In the TIME SCHEDULES menu
Display:
Press +or – to scroll through the range numbers the press OK.
Now that the time range has been selected, the control mode must be selected.
Press OK to open the settings. Press + or – to display the following menus. Press OK to confirm your selection.
After confirming the control mode, the Selected Days submenu appears.
Press OK then select the days. Press + to enable a day and – to disable it.
The schedules are set in the following order: start hour, start minute, end hour, and end minute.
Press OK to set the hours then the minutes.
The unit status will be automatically updated.
All types of adjustment are possible (start time < end time, start time; start time = end time; start time > end time)
If the end time start time, the schedule will end on the following day.
In the HOLIDAY BANDS menu
Display:
TIME PROGRAMMING
ON
9-SCHEDULING
TIME SCHEDULES
HOLIDAY BANDS
TIMETABLE x ↑
↓
CONTROL MODE ↑
STP.1 - OFF ↓
CONTROL MODE ↑
STP.2 - OFF ↓
CONTROL MODE ↑
STP.1 – STP.2 ↓
CONTROL MODE ↑
STP.2 – STP.1 ↓
CONTROL MODE ↑
DISABLED ↓
SELECTED DAYS ↑
M T W T F S S ↓
START OF TIME yyHxx ↑
END OF TIME yyHxx •
HOLIDAY BANDS ↑
No x ↓
Increment number
selected (1 to 6)
The control mode is
displayed on line 2
The control mode is
displayed on line 2
Increment number
selected (1 to 6)
