RK25WO Mobile Computer
25-key Model
28-key Model
No.
Description
No.
Description
1
Power Button
2
Scan Window
3
Status LED
4
Receiver
5
Touchscreen
6
Scan Key
7
Microphone
8
Headset Jack
9
Side-Trigger
10
Micro USB Port
11
Camera
12
Camera Flash
13
Wrist Band Cover
14
Battery
15
Battery Cover Latch and Lock
16
Speaker
17
Volume Buttons
18
NFC Detection Area
19
Wrist Band Hole
20
Charging & Communication Pins
Note: Please refer to “Physical Keypad” for the difference between 28-key Model and 25-key
Model.
