CipherLab RK25WO

27
Quick Start
1.1.2. INSTALLING MEMORY CARD
The RK25WO mobile computer is equipped with 2 SIM card slots and 1 memory card slot (or
1 SIM, 1 SAM, and 1 memory card slot); however, the SIM card slots are with no function
for Wi-Fi only model.
To insert the cards:
1) Remove the battery as described in Remove Battery.
2) Slide the hinged cover backward, and swing the top to open.
3) Place the card into the slot with its metal contacts downward.
4) Close the hinged cover, and then push it toward to lock.
5) Replace the battery cover and push the battery latch back to the “Lock” position.
○
2
Swing to open
○
1
Close the
hinged cover
○
1
Slide the
hinged cover
○
2
Slide the hinged
cover to lock
SIM 2/ SAM Card Slot
is with no function for
Wi-Fi only model
SIM 1 Slot
is with no function for
Wi-Fi only model
Micro SD Card Slot
Supports
SD/SDHC/SDXC
