CipherLab RK25WO

28
RK25WO Mobile Computer
REMOVE THE CARD
1) Remove the battery cover as described in Remove Battery.
2) Slide the hinged cover backward, and swing the top to open.
3) Take out the card directly from the slot.
4) Close the hinged cover, and then push it toward to lock.
5) Replace the battery cover and push the battery latch back to the “Lock” position.
○
2
Swing to open
○
1
Slide the
hinged cover
○
1
Close the
hinged cover
○
2
Slide the hinged
cover to lock
