Circutor AFQm 30 A - Page 94

94
AFQm
Instruction Manual
11
8
5
3
3
6
11
4
Wall bushing
Lower cover
Front cover
Figure 94:Steps to change fans (Part 1).
12
10
9
9
7
6
Figure 95:Steps to change fans (Part 2).
3 Remove the 8 screws from the front cover.
2
4 Disconnect the display.
