Active Power Parameters
L1 Active power (kW or MW)
L2 Active power (kW or MW)
L3 Active power (kW or MW)
Active Power III(kW or MW)
Display the minimum values.
Display the maximum values.
Inductive Reactive Power Parameters
L1 Inductive Reactive Power
L2 Inductive Reactive Power
L3 Inductive Reactive Power
Inductive Reactive Power III
(kvarL or MvarL)
Display the minimum values.
Display the maximum values.
Capacitive Reactive Power Parameters
L1 Capacitive Reactive Power
L2 Capacitive Reactive Power
L3 Capacitive Reactive Power
Capacitive Reactive Power III
(kvarC or MvarC)
Display the minimum values.
Display the maximum values.
