The key skips to the previous digit.
The key skips to the next digit.
The key increases the digit value and the key reduces the digit value.
Press to validate the data; the symbol disappears from the display.
Minimum value: 0.02
Maximum value: 1.0
If the value entered is lower than the minimum value or higher than the maximum value, the backlight
of the display flashes and the value entered is replaced with the minimum or maximum value, or with
the last value validated.
Press the key to access the next programming step.
If no keys are pressed for 5 minutes, the device switches to the simulation screen, “5.30.- SIMULATION
SCREEN”.
5.10.- VOLTAGE LEVEL
In this point the voltage level of the device is selected. There are two possible options:
Louu.U: Low voltage
High.U: High voltage
84
Computer SMART III
Instruction Manual
