B.- Programming variables
The following functions are implemented for these variables:
Function 04: reading logs.
Function 10: Writing multiple logs.
Table 16:Modbus memory map: programming variables (Table 1)
Device parameters
Configuration variable Address
Serial number
(8)
1000-1003
Frame number
(8)
1010-1013
Version
(8)
1020-1021
Hardware log
(8)
1030-1033
(8)
The parameters of the device have only implemented function 04.
Table 17:Modbus memory map: programming variables (Table 2)
Communications
Configuration variable Address Valid data window Default value
Peripheral no. 1071 1 to 254 1
Speed 1072 0 (9600), 1 (19200) 1
Parity 1073 0 (none), 1 (odd), 2 (even) 0
Length 1074 0 (8 bits), 1 (7 bits) 0
Stop bits 1075 0 (1 bits), 1 (2 bits) 0
Table 18:Modbus memory map: programming variables (Table 3)
Transformation ratios
Configuration variable Address Valid data window Default value
Current primary 1090 1 - 10000 5
Current secondary 1091 0 (1 A), 1 (5 A) 1
Voltage primary 1095-1096 1 - 99999 400
Voltage secondary 1097-1098 1 - 99999 400
Table 19:Modbus memory map: programming variables (Table 4)
Connection type
Configuration variable Address Valid data window Default value
Connection type 1100 0 (3U.3C), 1 (3U.1C), 2 (2U.1C) 0
Phase
(9)
1101 1 to 6 (Table 42) 1
Current 1
(9)(10)
1102 1 (Phase 1 direct), 2 (Phase 2 direct),
3 (Phase 3 direct),
4 (Phase 1 reverse),
5 (Phase 2 reverse),
6 (Phase 3 reverse),
1
Current 2
(9)(10)
1103 2
Current 3
(9)(10)
1104 3
(9)
Only used when the connection type is other than 3U.3C.
(10)
Indicates the relationship between the assigned voltage and the current direction.
Example: If you see Current 1 = 1, Current 2 = 5 and Current 3 = 3, this means that:
Current 1 is assigned to voltage 1 in the direct direction, current 2 is assigned to voltage 2 in the reverse
direction and current 3 is assigned to voltage 3 in the direct direction.
