Operation
Generic functions of the front keypad:
Key Reset:
Starting the equipment.
Deletion of Maximum and Minimum values.
This is equivalent to starting the equipment in the absence of
voltage.
Key Display:
Displaying all variables by repeated presses.
Function key in set-up menu: pressing the Display key moves
forward through different screens, both on the configuration menu
and the communications menu.
In runtime mode, a long press (keeping the key pressed for 2
seconds), displays the energy meters:
9 Active Energy Consumed
9 Reactive Inductive Energy Consumed
9 Reactive Capacitive Energy Consumed
9 Apparent energy Consumed
9 Active energy Generated
9 Inductive Reactive Energy Generated
9 Reactive Capacitive Energy Generated
9 Apparent Energy Generated
Key Max and Min:
Display of maximums or minimums for each variable displayed; this
function is only valid while the key is being pressed. Once it is
stopped being pressed the instant values appears again after five
seconds.
Function keys in set-up menu: the MIN key selects the code or
parameter to be changed and the MAX key assigns the
corresponding code and/or variable.
